Model:

• CS 3016G
• CS 3024G
• CS 3060G / 3060D

Form Factor:

• 3U 16-bay
• 4U 24-bay
• 4U 60-bay

Node:

• G model: Single node
• D model: Dual nodes

Number of Nodes: 1 to 144

File System: Infortrend Distributed File System (IDFS)

Cache Memory (per Node): Default DDR4 64GB, up to 256GB

Front-end Network (per Node): 10GbE (SFP+) x 2 or 10GbE (SFP+) x 4 or 25GbE (SFP28) x 2 or 40GbE (QSFP+) x 2

Internal Network (per Node): 10GbE (SFP+) x 2 or 25GbE (SFP28) x 2 or 40GbE (QSFP+) x 2

Network Type Combinations:

• Combination 1: Front-end (onboard 10GbE x 2) + Internal (onboard 10GbE x 2)
• Combination 2: Front-end (onboard 10GbE x 4) + Internal (host board 25GbE x 2)
• Combination 3: Front-end (onboard 10GbE x 4) + Internal (host board 40GbE x 2)
• Combination 4: Front-end (host board 25GbE x 2) + Internal (host board 25GbE x 2)
• Combination 5: Front-end (host board 40GbE x 2) + Internal (host board 40GbE x 2)
• Combination 6: Front-end (onboard 10GbE x 4 + host board 25GbE x 2) + Internal (host board 25GbE x 2)
• Combination 7: Front-end (onboard 10GbE x 4 + host board 40GbE x 2) + Internal (host board 40GbE x 2)

Drive Interface: 12Gb/s SAS

Supported Drives: 3.5" nearline SAS or SATA HDD

For the latest compatibility details, please refer to the EonStor CS Compatibility Matrix.

Max. Drive Number: 120 (per node, varies by model)

Data Protection:

• Disk protection: RAID 5, RAID 6
• Node protection: Erasure code (2+1 or 4+1 or 4+2 or 8+1 or 8+2) or Replica (x2 or x3)
• Cluster protection: Rsync

Data Services:

• Default software features include:
• SED (self-encrypting drives)
• SSD cache: support 1 SAS/SATA SSD per node as read cache
• DNS Load Balance: round robin
• Optional software features require additional license:
• WORM
• Automated storage tiering: 4 tiers per pool
• SSD cache: support 2, 4, 6 or 8 SAS/SATA SSD per node as read cache
• Advanced DNS Load Balance: connection number, network throughput, CPU usage

Supported OS: Windows Server 2016, Windows Server 2012 R2, CentOS

For supported OS versions, please refer to the EonStor CS Compatibility Matrix.

Supported Protocols: CIFS/SMB, NFS, FTP

Management:

• ACL control
• Quota management
• User account management
• Web-based EonOne management software
• Microsoft Active Directory (AD), Linux LDAP and NIS authentication
• Storage Resource Management to analyze history records of resource usage

Notification: Email, SNMP traps

Expansion Enclosures (JBODs): JB 3016, JB 3060L

Availability and Reliability: SMB Multichannel, Self-healing

Safety Standards

• Safety: UL, BSMI, CB
• Electromagnetic compatibility: CE, BSMI, FCC

Green Design:

• 80 PLUS-certified power supplies delivering more than 80% energy efficiency
• Intelligent multi-level drive spin-down

Power Supply Unit:

• Power supplies:
• 4U 60-bay: 1600W (80 PLUS Platinum)
• The other form factors: 530W (80 PLUS Bronze)
• AC voltage:
• 4U 60-bay: 200-240VAC @9.6A
• The other form factors: 100-127VAC @13.8A to 200-240VAC @9.6A
• Frequency: 47-63 Hz

Environmental:

• Temperature:
• Operating: 0°C to 35°C
• Non-operating: -40°C to 60°C
• Altitude:
• Operating: sea level to 3,660 m (12,000 ft)
• Non-operating: sea level to 12,192 m (40,000 ft)
• Relative humidity: 5% to 95% non-condensing, operating and non-operating

Service and Support:

• Standard service: 3-year limited hardware warranty and 8x5 phone, web, and email support (batteries are covered under warranty for 2 years).
• Warranty extension: standard service can be extended up to 5 years.
• Service upgrade options: the following service can be upgraded to 5 years
• Upgrade: replacement part dispatch on the next business day.
• Advanced service: 24x7 phone, web, and email support + onsite diagnostics on the next business day.
• Premium service: 24x7 phone, web, and email support + onsite diagnostics in 4 hours.
• Technical support: installation/maintenance guide, software/firmware download, troubleshooting and support tickets.
• Product services: product registration, licensing service, product repair, and order status.

Options may vary by region. For more details, please contact our sales representatives.

Dimensions (W x H x D):

• 3U 16-bay: 449 x 130 x 500 mm
• 4U 24-bay: 449 x 174.4 x 500 mm
• 4U 60-bay: 447.6 x 176 x 840.9 mm

Package Dimensions (W x H x D):

• 3U 16-bay: 780 x 423 x 588 mm
• 4U 24-bay: 780 x 465 x 588 mm
• 4U 60-bay: 620 x 460 x 1,140 mm

Weight (without HDDs):

• 3U 16-bay: 34.83 lbs (15.8 kg)
• 4U 24-bay: 47.02 lbs (21.32 kg)
• 4U 60-bay: 69.45 lbs (31.5 kg)
