Model:

• GS 4012 G3
• GS 4016 G3
• GS 4024 G3
• GS 4040 G3
• GS 4060 G3
• GS 4090 G3


Form Factor:

• 2U 12-bay
• 3U 16-bay
• 4U 24-bay
• 4U 40-bay
• 4U 60-bay
• 4U 90-bay

Cache Memory:

• Single controller::
• 4U 40-bay/60-bay: Default DDR4 12GB, up to 192GB
• 4U 90-bay: Default DDR4 16GB, up to 192GB
• The other form factors: Default DDR4 8GB, up to 192GB
• Dual redundant controllers:
• 4U 40-bay/60-bay: Default DDR4 24GB, up to 384GB
• 4U 90-bay: Default DDR4 32GB, up to 384GB
• The other form factors: Default DDR4 16GB, up to 384GB

Host Ports:

• Host board options:
• 16Gb/s FC x 4
• 32Gb/s FC x 2
• 32Gb/s FC x 4
• 10GbE (SFP+) x 2
• 25GbE (SFP28) x 2
• 100GbE (QSFP28) x 1, RDMA (for 40-bay/60-bay/90-bay models only)
• 100GbE (QSFP28) x 2, RDMA (for 40-bay/60-bay/90-bay models only)
• 12Gb/s SAS x 2

Supported Drives:

• 2.5" SAS SSD
• 2.5" 12Gb/s SAS 10,000 RPM HDD
• 3.5" 12Gb/s NL-SAS 7,200 RPM HDD
• 2.5" SATA SSD, 3.5" 6Gb/s SATA 7,200 RPM HDD (for single-controller models only)
• 2.5" U.2 NVMe SSD (for U.2 SSD cache models; must be purchased from Infortrend)

Max. Drive Number:

• Per appliance: 896 (via expansion enclosure)
• Per cluster: 3,584 (via scale-out with other series of appliances)

RAID Options: RAID 0, RAID 1, RAID 3, RAID 5/5F, RAID 6/6F, RAID 10, RAID 30, RAID 50, RAID 60

Data Services:

• Default software features include:
• Thin provisioning (block level)
• Scale-out (file level): 1 appliance per cluster
• Scale-out (block level): 4 appliances per cluster
• Snapshot (block level): 64 per source volume, 128 per pool
• Local replication: 4 per source volume, 16 per system
• Remote replication (file level): Rsync with 128-bit SSH encryption
• Optional software features require additional license:
• HA Service (block level, file level)
• SSD cache (block level, file level)
• Automated storage tiering: 4 tiers per pool
• Advanced scale-out (file level): 4 appliances per cluster
• Advanced snapshot (file level): 1,024 per folder
• Advanced snapshot (block level): 256 per source volume, 4,096 per pool
• Advanced local replication: 8 per source volume, 256 per system
• Advanced remote replication (block level): 8 per source volume, 64 per system

Supported OS:

• Microsoft Windows Server 2019/2016/2012 R2/2012/2008 R2/2008
• Windows 7 SP1
• Windows 8.1
• Windows Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise
• Sun Solaris
• macOS X
• VMware
• Citrix XenServer
• OpenStack Cinder

Supported Protocols:

• File level: CIFS/SMB (version 2.0/3.0), NFS (version 2/3/4), AFP (version 3.1.12), FTP/FXP (vsftp 2.3.4), WebDAV (httpd package 2.4.6)
• Block level: FC, iSCSI, SAS
• Object level: RESTful API

Cloud Gateway: EonCloud Gateway supports integration with the following cloud providers:

• Amazon S3
• Microsoft Azure
• Alibaba Cloud
• Google Cloud
• Baidu Cloud
• Tencent Cloud
• OpenStack
• Wasabi
• Yandex
• hiCloud

For complete information about Cloud providers' support, please refer to EonCloud Gateway webpage.

Management:

• Web-based EonOne management software
• User account management
• Group management
• Folder management - folder access control
• Quota management
• Folder encryption with AES
• Integration with Microsoft Active Directory (AD) and Linux LDAP
• Storage Resource Management to analyze history records of resource usage
• Multi-factor authentication login mechanism
• File-level QoS (network traffic control)
• SMI-S standard interface for Hypervisor management applications

Notification: Email, SNMP traps

Expansion Enclosures (JBODs):

• 2U 12-bay: JB 3012A, JB 3016A, JB 3060L, JB 3090
• 3U 16-bay: JB 3016A, JB 3060L, JB 3090
• 4U 24-bay/40-bay/60-bay/90-bay: JB 3060L, JB 3090

Availability and Reliability:

• Immutable object storage
• Hot-swappable hardware modules
• Device mapper
• Antivirus
• Trunk group
• Cache safe technology
• UPS
• WORM (file level only)
• SMB Multichannel
• Backup service

Safety Standards:

• Safety: UL, BSMI, CB
• Electromagnetic compatibility: CE, BSMI, FCC

Green Design:

• 80 PLUS-certified power supplies delivering more than 80% energy efficiency
• Intelligent multi-level drive spin-down

Power Supply Unit:

• Power supplies: redundant (1+1) and hot-swappable
• 4U 40-bay/60-bay: 1300W x 2 (80 PLUS Titanium)
• 4U 90-bay: 1600W x 2 (80 PLUS Titanium)
• The other form factors: 800W x 2 (80 PLUS Titanium)
• AC voltage:
• 4U 40-bay/60-bay: 100-127VAC @10A, 200-240VAC @8.5A
• 4U 90-bay: 100-127VAC @12A, 200-240VAC @10A
• The other form factors: 100-127VAC @10A, 200-240VAC @5A
• Frequency: 50-60 Hz
