– 802.11ac Wave 2 with 2×2:2 MIMO technology uses two spatial streams when operating in SU-MIMO or MU-MIMO mode, offering 867-Mbps rates for more capacity and reliability than competing access points.

– Flexible deployment through the Mobility Express solution is ideal for small to medium-sized deployments. Easy setup allows the 1100 Series to be deployed on networks without a physical controller.

– For more information, view theCisco Aironet 1815i Access Point Data Sheet.

– Flexible deployment through theMobility Express solution is ideal for small to medium-sized deployments. Easy setup allows the 1815i to be deployed on networks without a physical controller.

– 802.1X, RADIUS AAA.

– 802.11r.

– 802.11i.

– Maximal Ratio Combining (MRC).

– 20-, 40-, and 80-MHz channels.

– PHY data rates up to 866.7 Mbps (80 MHz on 5 GHz).

– Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Rx).

– 802.11 Dynamic Frequency Selection (DFS).

– Cyclic Shift Diversity (CSD) support.

– ITU G.993.2 (VDSL2) and supported profiles: 8a, 8b, 8c, 8d, 12a, 12b, and 17a.

– VDSL2 Vectoring.

– ADSL Annex A and Annex B ITU G. 992.1 (ADSL), G.992.3 (ADSL2), and G.992.5 (ADSL2+).

– ADSL Annex M G.992.3 (ADSL2) and G.992.5 (ADSL2+).

– AC input voltage: Universal 100 to 240 VAC.

– Frequency: 50 to 60 Hz.

– Maximum output power: 66W (default).

– Output voltages: 12 VDC.

– Optional PoE and PoE+:

◦   Single 125W power supply required for Cisco 1100-8P router

◦   Single 115W power supply required for Cisco 1100-4P router

– External output voltage: 48 VDC.

◦   USB eTokens

◦   USB flash memory

– Note: Devices USB 3.0 supports to be connected externally. View the
USB Device Support Data Sheet.

– SIM status (green/amber).

– Received Signal Strength Indication (RSSI) bar (green).

– 3G/LTE service (green/amber).

– GPS (green/amber).

– Speed and link for Gigabit Ethernet WAN port (green).

– Speed and link for all Fast Ethernet LAN ports (green).

(H x W x D)

– 1.75 x 12.7 x 9.03 in. (42 x 323 x 230mm) (includes rubber feet on non-LTE models).

– CAN/CSA C22.2 No. 60950-1, 2nd edition.

– EN 60950-1, 2nd edition.

– CB to IEC 60950-1, 2nd edition with all group differences and national deviations.

– Nonoperating humidity: 5% to 95% relative humidity (noncondensing).

– Nonoperating altitude: 0 to 15,000 ft (0 to 4570 m).

– Operating temperature: 32° to 104°F (0° to 40°C).

– Operating humidity: 10% to 85% relative humidity (noncondensing).

– Operating altitude: 0 to 10,000 ft (0 to 3000 m).
