Specifications

Output

• Output power capacity: 900Watts / 1.5 kVA

• Max Configurable Power (Watts): 900Watts / 1.5 kVA

• Nominal Output Voltage: 230V

• Output Voltage Distortion: Less than 5% at full load

• Output Frequency (sync to mains): 57 - 63 Hz for 60 Hz nominal

• Topology: Line Interactive

• Waveform type: Sine wave

• Output Connections

(2) IEC Jumpers (Battery Backup)

(4) IEC 320 C13 (Battery Backup)

• Transfer Time: 2ms typical

Input

• Nominal Input Voltage: 230V

• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)

• Input Connections: IEC-320 C14

• Input voltage range for main operations: 180 - 287V

• Input voltage adjustable range for mains operation: 170 - 300V

• Number of Power Cords: 1

• Other Input Voltages: 220, 240

Batteries & Runtime

• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

• Typical recharge time: 3hour(s)

• Replacement Battery: APCRBC142
