Product Code

LR5A42

Form Factor

Mid-tower

Processor

CPU

Intel® Xeon® E Processors (up to 95W TDP)

Socket

Single Socket H4 (LGA 1151)

System Memory

Memory Capacity

Up to 64GB ECC UDIMM

Memory Type

Dual Channel DDR4 2666/2400/2133MHz ECC UDIMM

DIMM Size

64GB, 32GB, 16GB, 8GB

Socket

4x 288-pin DDR4 DIMM slots

Chipset

Intel® C246 chipset

Expansion Slots

．2x PCI-E 3.0 x16 running at NA/16 or 8/8,

．1x PCI-E 3.0 x4 slot

．1x PCI-E 3.0 x1 slot

．2x M.2 Interface: PCI-E 3.0 x4

M.2 Form Factor: 2260/2280/22110

M.2 Key: M-Key

．1x U.2 Interface: 1 PCI-E 3.0 x4

Drive Bay

．2x 5.25" drive bays (one for DVD-RW)

．1x fixed 3.5" drive bay

．4x 3.5" rotatable internal drive bays

．4x 2.5" internal drive bays

Optical Drive

Super Multi Drive: DVD-ROM, DVD-R/RW/RAM/+R/RW +/-R DL M-DISC/+M SL read and write compatible

On-board Device

SATA

．SATA3 (6Gbps) via Intel C246 controller

．RAID 0, 1, 5, 10 support

Network

．Single LAN with Intel® PHY I219LM LAN controller

．Single LAN with Aquantia 5G LAN chip AQC108

Front Bezel

Switch

Power

LED Indicator

．Hard drive activity LED

．Network activity LED

．System status LED

I/O Ports

Serial ATA

8x SATA3 (6Gbps) ports

LAN

2x RJ45 Ethernet LAN ports

USB

．Front: 2x USB 3.0,

2x USB 2.0

．Rear: 2x USB 3.1 Gen 2 Type A and Type C 2x USB 3.1 Gen 1

Audio

2x3 Phone Jack, 7.1 HD Audio with optical S/PDIF

TPM

1x TPM 2.0 Header

Power Supply

500W 80Plus Bronze Certified

OS

Windows 10, RHEL 7.5, and Ubuntu 18.04 LTS

Dimensions (DxWxH)

525.3 x 193 x 424 mm
