Product SKUs

X11DPX-T

Physical Stats

Form Factor

E-ATX

Dimensions

12" x 13" (30.48cm x 33.02cm)

Processor/Cache

CPU

Dual Socket P (LGA 3647)
Intel® Xeon® Scalable Processors, 3 UPI up to 10.4GT/s
Support CPU TDP 70-255W with IVR

Cores / Cache

Up to 28 Cores with Intel® HT Technology

System Memory

Memory Capacity

16 DIMM slots
Up to 2TB ECC 3DS LRDIMM, 512GB ECC RDIMM, DDR4 up to 2666MHz

Memory Type

2666/2400/2133MHz ECC DDR4 SDRAM

Memory Voltage

1.2 V

Error Detection

Corrects single-bit errors
Detects double-bit errors (using ECC memory)

On-Board Devices

Chipset

Intel® C621

SATA

SATA3 (6Gbps) with RAID 0, 1, 5, 10

IPMI

Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Network Controllers

Intel® X550-AT2 Dual Port 10GBase-T

Graphics

ASPEED AST2500 BMC

Input / Output

SATA

10 SATA3 (6Gbps) ports

USB

2 USB 3.0 ports (rear)
2 USB 2.0 ports (rear)

VideoOutput

1 VGA port

TPM

1 TPM 2.0 Header

LAN

2 RJ45 10GBase-T ports
1 RJ45 Dedicated IPMI LAN port

DOM

2 SuperDOM (Disk on Module) ports

Serial Port / Header

1 COM port (rear)

Expansion Slots

PCI-Express

2 PCI-E 3.0 x16 slots (HSSI)
2 PCI-E 3.0 x16 slots (or 4 PCI-E 3.0 x8 by Mixed)
4 PCI-E 3.0 x8 slots
1 PCI-E 3.0 x4 (in x8 slot)

System BIOS

BIOS Type

AMI UEFI

Management

Software

Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SSM, SUM, SuperDoctor® 5

Power Configurations

ACPI Power Management

PC Health Monitoring

CPU

Monitors for CPU Cores, Chipset Voltages, Memory.
4+1 Phase-switching voltage regulator

FAN

Fans with tachometer monitoring
Status monitor for speed control

Monitoring for CPU and chassis environment
Thermal Control for fan connectors

Temperature

CPU thermal trip support

LED

CPU / System Overheat LED

Other Features

ACPI power management, Chassis intrusion detection, CPU thermal trip support for processor protection, Node Manager Support, RoHS, UID
