Output

Output Power Capacity: 2700 Watts / 2200 VA

Max Configurable Power: 2700 Watts / 2200 VA

Nominal Output Voltage: 230V

Output Voltage Note:

Configurable for 220 : 230 or 240 nominal output voltage

Output Frequency (sync to mains):

47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal

Other Output Voltages: 220, 240

Topology: Line Interactive

Waveform Type: Sine wave

Output Connections:

(8) IEC 320 C13

(1) IEC 320 C19

(3) IEC Jumpers

Input

Nominal Input Voltage: 230V

Input Frequency: 50/60 Hz +/- 3 Hz (auto sensing)

Input Connections:

British BS1363A

IEC-320 C20

Schuko CEE 7/EU1-16P

Cord Length: 2 meters

Input voltage range for main operations: 160 - 286V

Input voltage adjustable range for mains operation: 151 - 302V

Other Input Voltages: 220, 240

Batteries & Runtime

Battery Type:

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time: 3 hour(s)

Replacement Battery: RBC43

RBC™ Quantity: 1

Communications & Management

Interface Port(s): USB

Available SmartSlot™ Interface Quantity: 1

Control panel: Multi-function LCD status and control console

Audible Alarm:

Alarm when on battery : distinctive low battery alarm : configurable delays

Surge Protection and Filtering

Surge energy rating: 375 Joules

Physical

Maximum Height: 86.00 mm

Maximum Width: 480.00 mm

Maximum Depth: 683.00 mm

Rack Height: 2U

Net Weight: 42.31 KG

Shipping Weight: 49.73 KG

Shipping Height: 254.00 mm

Shipping Width: 600.00 mm

Shipping Depth: 980.00 mm

Units per Pallet: 8.00

Environmental

Operating Environment: 0 - 40 °C

Operating Relative Humidity: 0 - 95%

Operating Elevation: 0-3000 meters

Storage Temperature: -15 - 45 °C

Storage Relative Humidity: 0 - 95%

Storage Elevation: 0-15000 meters

Audible noise at 1 meter from surface of unit: 55.00 dBA

Online Thermal Dissipation: 215.00 BTU/hr
